Anti-DC-SIGNR [16E7]

Immunofluoresence staining of fixed HeLa cells with anti-DC-SIGNR antibody 16E7. Immunofluorescence analysis of paraformaldehyde fixed HeLa cells, permeabilized with 0.15% Triton stained with the chimeric rabbit IgG version of 16E7 (orb348892) at 10 µg/ml for 1h followed by Alexa Fluor® 488 secondary antibody (1 µg/ml), showing cytoplasmic staining. The nuclear stain is DAPI (blue). Panels show from left-right, top-bottom orb348892, DAPI, merged channels and a negative control. The negative control was stained with unimmunized rabbit IgG followed by Alexa Fluor® 488 secondary antibody.

Western Blot using anti-DC-SIGNR (CLEC4M) antibody 16E7 Jurkat cell extract (35 µg protein in RIPA buffer) was resolved on a 10% SDS PAGE gel and blots probed with the chimeric rabbit version of 16E7 (orb348892) at 0.1 µg/ml before detection using an anti-rabbit secondary antibody. A primary incubation of 1h was used and protein was detected by chemiluminescence. The expected band size for DC-SIGNR is 45.3kDa, though 9 other isoforms of this protein are known ranging in size from 22.4-44.7kDa (Uniprot ID: Q9H2X3). DC-SIGNR is also glycosylated at several positions. orb348892 successfully detected the canonical human DC-SIGNR, as well as multiple other isoforms.
